- General Information
- Manufacturer
- Netgear, Inc
- Manufacturer Website Address
- http://www.netgear.com.au
- Brand Name
- Netgear
- Product Line
- ProSafe Plus
- Product Type
- Ethernet Switch
More Capabilities beyond Plug-and-play Connectivity
Today's growing businesses are both placing more demands on and relying more on their network. Companies are putting more applications and demands on their Ethernet Infrastructure. Using VoIP phones and IP cameras require more than simple plug-and-play connectivity. Additionally, Internet-based applications such as Hotmail and Google Calendaring have made keeping the network up a business-critical need. However, companies do not necessarily have more money or advanced training to deal with complex managed switches. NETGEAR's new ProSafe Plus Switches meet this growing need by providing easy to use visibility and limited configuration capabilities. To provide more insight into the network behavior, ProSafe Plus Switches offer traffic monitoring for users to observe traffic behavior. Additionally, if there are connectivity issues, these switches offer a cable diagnostic test capability that can identify and even locate problems in the cables. To optimize traffic through the switches, ProSafe Plus Switches offer both port and tag-based prioritization to keep latency-sensitive traffic moving ahead of less critical packets. Also, as a means of improving security or managing collision domains, ProSafe Smart Switches offer VLAN technology. ProSafe Plus Switches offering these monitoring and configuration capabilities at a slight cost premium over un anaged switches, delivering great value to the end user.
- Warranty
- Limited Warranty
- Lifetime
- Interfaces/Ports
- Total Number of Network Ports
- 5
- Token Ring Port
- No
- LRE Port
- No
- Uplink Port
- No
- Bypass
- No
- Modular
- No
- Management Port
- No
- USB
- No
- Stack Port
- No
- Number of Network (RJ-45) Ports
- 5
- Port/Expansion Slot Details
- 5 x Gigabit Ethernet Network
- Media & Performance
- Media Type Supported
- Twisted Pair
- Twisted Pair Cable Standard
- Category 5
- Ethernet Technology
- Gigabit Ethernet
- Network Technology
- 10/100/1000Base-T
- Network & Communication
- Layer Supported
- 2
- Management & Protocols
- Manageable
- Yes
- Management
- Web Based Managment
- Power Description
- PoE (RJ-45) Port
- No
- Power Source
- Power Adapter
- Physical Characteristics
- Form Factor
- Desktop
- Wall Mountable
- Height
- 660.4 mm
- Width
- 2565.4 mm
- Depth
- 2387.6 mm
- Weight (Approximate)
- 270 g
- Miscellaneous
- Package Contents
- ProSafe Plus GS105Ev2 Ethernet Switch
- Power Adapter
- Rack-Mounting Kit
- Quick Install Guide
- Resource CD with PC Utility Software
- Certifications & Standards
IEEE Standards:
- 802.3i
- 802.3u
- 802.3ab
- 802.3x
- 802.1p
Safety Agency Approvals:
- UL listed (UL 1950)/CUL
- CB
Electromagnetic Compliance:
- CE mark (commercial)
- FCC Part 15 Class B
- EN 55022 (CISPR 22)Class B
- VCCI Class B
- C-Tick
