- General Information
- Manufacturer
- Atdec Pty Ltd
- Manufacturer Website Address
- http://www.atdec.com.au
- Brand Name
- Atdec
- Product Type
- Wall Mount
The TH-3070-UF is the ideal wall mounting solution for large screen displays weighing up to 200lb. The mount holds a wide variety of screens thanks to its universal mounting hole pattern that fits to most VESA and non-VESA screens (up to 800 wide). Installation is simple and quick, with the option of a theft-resistant security bar for added protection. Even after installation, screen height is easily changed (via 3 height positions). The wall mount sits 1.53in from the wall.
- Warranty
- Limited Warranty
- 10 Year
- Product Information
- Device Supported
- Flat Panel Display
- Number of Displays Supported
- 1
- Maximum Load Capacity
- 90.72 kg
- Minimum Screen Size Supported
- 106.7 cm
- Maximum Screen Size Supported
- 203.2 cm (80")
- Features
- Tilt
- Lockable
- Anti-theft
- Heavy Duty
- Durable
- Adjustable Tilt
- Flexible
- Padlock
- Physical Characteristics
- Product Color
- Black
- Finishing
- Black
- VESA Mount Compatible
- Yes
- Mounting Pattern
- 200 x 100
- 200 x 200
- 300 x 200
- 300 x 300
- 400 x 300
- 400 x 400
- 600 x 400
- 800 x 200
- 800 x 400
- Product Material
- Steel
- Depth
- 7.6 cm
- Miscellaneous
- Package Contents
- Wall Plate
- Security Plate
- Display Bracket (left)
- Display Bracket (right)
- Fasteners
- 4 x Coach Screw
- 4 x Masonry Wall Plug
- 4 x Multi Washer
- 4 x Washer
- 6 x Dry Wall Anchor
- 4 x 13mm Spacer Bush
- 4 x 20mm Spacer Bush
- 4 x (M8x15mm) Cross Recessed Screws
- 4 x (M8x35mm) Cross Recessed Screws
- 4 x (M8x45mm) Cross Recessed Screws
- 4 x (M6x15mm) Cross Recessed Screws
- 4 x (M6x35mm) Cross Recessed Screws
- 4 x (M6x45mm) Cross Recessed Screws
- 4 x (M5x15mm) Cross Recessed Screws
- 4 x (M5x35mm) Cross Recessed Screws
- 4 x (M5x45mm) Cross Recessed Screws
- 4 x (M4x15mm) Cross Recessed Screws
- 4 x (M4x35mm) Cross Recessed Screws
- 4 x (M4x45mm) Cross Recessed Screws
- Application/Usage
- Wall
- Additional Information
- Mounting Hole Pattern (mm): From 180-800 Wide x 125-500 high
- Compatibility
- LCD
- LED
- Plasma
- Assembly Required
- Yes
